SpareCrux

SPARECRUX is an authorized distributor for HENSEL ELECTRIC

KF 0604 V | HENSEL | Cable Junction Boxes IP 66/67 With PE Inlay

₹ 1,588.00

●   Available for backorder, with an estimated lead time of 8 to 12 weeks.

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Manufacturer Part Number (MPN)

KF 0604 V

Original Equipment Manufacturer

HENSEL ELECTRIC

Description

KF 0604 V

  • 1.5-4 mm², Cu 3~
  • Terminal with 2 clamping units per pole
  • 5-pole per pole 8 x 1,5 mm² r / f, 6 x 2,5 mm² r / f, 4 x 4 mm² r / f, 2 x 6 mm² r / f
  • With patented PE inlay to connect the armours of SWA cables
  • Cable entries via knockouts, order ASS / GSC separately (see cable entry systems LES)
  • "Weatherproof" resistant to weather influences (UV due to solar radiation, protected against rainwater, temperature resistant, impact resistant, etc.)
  • Saltwater-proof
  • "Offshore applications"
  • Lid fasteners sealable without accessories
  • Retaining strap and external brackets for wall fixing included
  • Colour: black, RAL 9011

Technical Data

insulation voltage Ui = 690 V A.C./D.C.
rated current: 32 A
material PC-GFS (polycarbonate)
width 130 mm
height 130 mm
depth 77 mm
weight 0,354 kg
tightening torque for terminal 0.7 Nm
degree of protection IP 66 / IP 67
IP 67, temporary submersion
in accordance with IEC 60670-22
HENSEL ELECTRIC

KF 0604 V | HENSEL | Cable Junction Boxes IP 66/67 With PE Inlay

₹ 1,588.00

KF 0604 V

  • 1.5-4 mm², Cu 3~
  • Terminal with 2 clamping units per pole
  • 5-pole per pole 8 x 1,5 mm² r / f, 6 x 2,5 mm² r / f, 4 x 4 mm² r / f, 2 x 6 mm² r / f
  • With patented PE inlay to connect the armours of SWA cables
  • Cable entries via knockouts, order ASS / GSC separately (see cable entry systems LES)
  • "Weatherproof" resistant to weather influences (UV due to solar radiation, protected against rainwater, temperature resistant, impact resistant, etc.)
  • Saltwater-proof
  • "Offshore applications"
  • Lid fasteners sealable without accessories
  • Retaining strap and external brackets for wall fixing included
  • Colour: black, RAL 9011

Technical Data

insulation voltage Ui = 690 V A.C./D.C.
rated current: 32 A
material PC-GFS (polycarbonate)
width 130 mm
height 130 mm
depth 77 mm
weight 0,354 kg
tightening torque for terminal 0.7 Nm
degree of protection IP 66 / IP 67
IP 67, temporary submersion
in accordance with IEC 60670-22
