KF 0600 U | HENSEL | Cable Junction Boxes IP 66/67 With PE Inlay

₹ 1,368.00

●   Available for backorder, with an estimated lead time of 8 to 12 weeks.

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Manufacturer Part Number (MPN)

KF 0600 U

Original Equipment Manufacturer

HENSEL ELECTRIC

Description

KF 0600 U

  • Without terminals
  • With patented PE inlay to connect the armours of SWA cables
  • Cable entries via knockouts, order AKM / GSC separately (see cable entry systems LES)
  • "Weatherproof" resistant to weather influences (UV due to solar radiation, protected against rainwater, temperature resistant, impact resistant, etc.)
  • Saltwater-proof
  • "Offshore applications"
  • Lid fasteners sealable without accessories
  • Retaining strap and external brackets for wall fixing included
  • Colour: grey, RAL 7035

Technical Data

rated insulation voltage Ui = 1000 V A.C./D.C.
material PC-GFS (polycarbonate)
rated current: 32 A
mounting width 102 mm
mounting height 102 mm
max. installation depth 62 mm
width 130 mm
height 130 mm
depth 77 mm
weight 0,316 kg
degree of protection IP 66 / IP 67
IP 67, temporary submersion
in accordance with IEC 60670-22
HENSEL ELECTRIC

KF 0600 U | HENSEL | Cable Junction Boxes IP 66/67 With PE Inlay

₹ 1,368.00

KF 0600 U

  • Without terminals
  • With patented PE inlay to connect the armours of SWA cables
  • Cable entries via knockouts, order AKM / GSC separately (see cable entry systems LES)
  • "Weatherproof" resistant to weather influences (UV due to solar radiation, protected against rainwater, temperature resistant, impact resistant, etc.)
  • Saltwater-proof
  • "Offshore applications"
  • Lid fasteners sealable without accessories
  • Retaining strap and external brackets for wall fixing included
  • Colour: grey, RAL 7035

Technical Data

rated insulation voltage Ui = 1000 V A.C./D.C.
material PC-GFS (polycarbonate)
rated current: 32 A
mounting width 102 mm
mounting height 102 mm
max. installation depth 62 mm
width 130 mm
height 130 mm
depth 77 mm
weight 0,316 kg
degree of protection IP 66 / IP 67
IP 67, temporary submersion
in accordance with IEC 60670-22
