K 0201 | HESNEL | EMPTY BOX IP 66
₹ 4,920.00
Unit price
/
Unavailable
Manufacturer Part Number (MPN)
K 0101
Original Equipment Manufacturer
HENSEL ELECTRIC
Description
Description
K 0201
- Built-in dimensions W 275 x H 275 x D 150 mm
- Enclosure size 2, type Mi
- For installation equipment on DIN rails or mounting plates (order separately)
- Max. installation depth with built-in mounting plate 146 mm,
with built-in DIN rail 135 mm - With opaque lid
- Lid fasteners for tool operation
- Sealable
- Box walls without knockouts
- Optional hinges for device installation in the lid
- External brackets for wall fixing as accessories
- Colour: grey, RAL 7035
- Material: PC (polycarbonate)
Technical Data
| rated insulation voltage | Ui = 690 V A.C. / 1000 V D.C. |
| impact strength | IK 08 (5 Joule) |
| static load | mounting plate or DIN rail = 6.5 kg lid = 1.6 kg |
| power dissipation capability at Δϑ = 40 K | Pde = 53 watts |
| wall thickness | enclosure = 3 mm lid = 3 mm |
| material | PC (Polycarbonate) |
| degree of protection | IP 66 |
| mounting width | 275 mm |
| mounting height | 275 mm |
| max. installation depth | 146 with built-in mounting plate mm |
| max. installation depth | 135 with built-in DIN rail mm |
| width | 300 mm |
| height | 300 mm |
| depth | 170 mm |
| weight | 2,01 kg |
| in accordance with | IEC 62208:2011 |
