SPARECRUX is an authorized distributor for HENSEL ELECTRIC

DK 5000 G | HENSEL | Cable junction box

₹ 3,932.00

●   Available for backorder, with an estimated lead time of 8 to 12 weeks.

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Manufacturer Part Number (MPN)

DK 5000 G

Original Equipment Manufacturer

HENSEL ELECTRIC

Description

DK 5000 G

  • Without terminals
  • With two cable entries M 32 from the rear side
  • Cable entries via knockouts, order AKM separately (see cable entry systems LES)
  • Lid fasteners sealable without accessories
  • External brackets for wall fixing included
  • Colour: grey, RAL 7035
Technical Data

Rated insulation voltage Ui = 1000 V A.C./D.C.
Material PC (Polycarbonate)
Degree of protection IP 66
Mounting width 320 mm
Mounting height 215 mm
Max. installation depth 106 mm
Width 355 mm
Height 255 mm
Depth 122 mm
Weight 1,365 kg
In accordance with IEC 60670-22
