DK 1600 G | HENSEL | Cable junction box
₹ 1,512.00
● Available for backorder, with an estimated lead time of 8 to 12 weeks.
Couldn't load pickup availability
Warranty
Warranty
We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.
Delivery and Shipping
Delivery and Shipping
We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.
DK 1600 G | HENSEL | Cable junction box
₹ 1,512.00
Unit price
/
Unavailable
Manufacturer Part Number (MPN)
DK 1600 G
Original Equipment Manufacturer
HENSEL ELECTRIC
Description
Description
DK 1600 G
- Without terminals
- Included cable entry: 3 x ESM 40, sealing range Ø 17-30 mm
- With two cable entries M 32 from the rear side
- Lid fasteners sealable without accessories
- External brackets for wall fixing included
- Colour: grey, RAL 7035
Technical Data
| Rated insulation voltage | Ui = 1000 V A.C./D.C. |
| Material | PC (Polycarbonate) |
| Degree of protection | IP 55 (ESM) |
| Degree of protection | IP 66 (AKM) |
| Mounting width | 175 mm |
| Mounting height | 120 mm |
| Max. installation depth | 76 mm |
| Width | 210 mm |
| Height | 155 mm |
| Depth | 92 mm |
| Weight | 0,444 kg |
| In accordance with | IEC 60670-22 |
