CMDB12 | CONNECTWELL | 10 sq.mm Modular Distribution Terminal Block With 4x10sqmm, 20x4sqmm Connection Points in Grey Colour
₹ 240.24
● Available for backorder, with an estimated lead time of 8 to 12 weeks.
Couldn't load pickup availability
Warranty
Warranty
We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.
Delivery and Shipping
Delivery and Shipping
We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.
CMDB12 | CONNECTWELL | 10 sq.mm Modular Distribution Terminal Block...
₹ 240.24
Unit price
/
Unavailable
Manufacturer Part Number (MPN)
CMDB12
Original Equipment Manufacturer
CONNECTWELL
Description
Description
CMDB blocks are a modified version of the CDB terminal blocks without the central incoming terminal connection.
Technical Data
| Rated Voltage | 1000 V |
| Rated Current - Input Side | 57 A |
| Rated Current - Output Side | 32 A |
| Tightening Torque - Input Side | 1.2 Nm |
| Tightening Torque - Output Side | 0.5 Nm |
| Housing Material | Polyamide |
| Standard Colour | Grey |
| Product Function | Modular Distribution Blocks |
| Wire Entry Orientation | Side Entry |
| Mounting Possibility | DIN 32/DIN 35/DIN 35-15 Rail |
| Screw Size | M4 for 10sqmm, M3 for 4sqmm |
| Operated by | Screwdriver |
| Rated Surge Voltage | 8 KV |
| Pollution Degree | 3 |
