SPARECRUX is NOT an authorized distributor for ALLEN BRADLEY

112-C09ACJE1C-3-4G-6P | ALLEN BRADLEY | Bulletin 112 - IEC Combination Starter, Fusible -ClassJ Disconnect Type, IP42 (Type 1 - Metal), 9 Amp

₹ 66,403.29

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Manufacturer Part Number (MPN)

112-C09ACJE1C-3-4G-6P

Original Equipment Manufacturer

ALLEN BRADLEY

Description
Number of indicator lights 1 None
Rated operation current Ie 9 A
Voltage type for actuating AC
With transformer True
Suitable for emergency stop True
External reset possible False
With short-circuit release True
With fuse True
Rated control supply voltage at AC 50 Hz 24 V
Rated control supply voltage at AC 60 Hz 24 V
Release class Adjustable
Overload release current setting 1 A
Type of motor starter Direct online starter (DOL)
Disconnect switch Standard fusing
Fuse clip rating 30 A maximum, Class CC
KW rating 4 kW @ 500V (AC3, AC4), 3-phase, 50 Hz
Hp rating 7.5Hp @ 575V (AC3, AC4), 3-phase, 60 Hz
Factory installed models HAND-OFF-AUTO selector switch
Temperature compensated overload protection True
Coordination class according to IEC 60947-4-3 Class 2
Type of electrical connection of main circuit Screw connection
Type of electrical connection for auxiliary- and control current circuit Screw connection
ALLEN BRADLEY

112-C09ACJE1C-3-4G-6P | ALLEN BRADLEY | Bulletin 112 - IEC Combination Starter, Fusible -ClassJ Disconnect Type, IP42 (Type 1 - Metal), 9 Amp

₹ 66,403.29
Number of indicator lights 1 None
Rated operation current Ie 9 A
Voltage type for actuating AC
With transformer True
Suitable for emergency stop True
External reset possible False
With short-circuit release True
With fuse True
Rated control supply voltage at AC 50 Hz 24 V
Rated control supply voltage at AC 60 Hz 24 V
Release class Adjustable
Overload release current setting 1 A
Type of motor starter Direct online starter (DOL)
Disconnect switch Standard fusing
Fuse clip rating 30 A maximum, Class CC
KW rating 4 kW @ 500V (AC3, AC4), 3-phase, 50 Hz
Hp rating 7.5Hp @ 575V (AC3, AC4), 3-phase, 60 Hz
Factory installed models HAND-OFF-AUTO selector switch
Temperature compensated overload protection True
Coordination class according to IEC 60947-4-3 Class 2
Type of electrical connection of main circuit Screw connection
Type of electrical connection for auxiliary- and control current circuit Screw connection
